Feature
Features :
1.The first generation multifunction bucket clamp is developed based on the bucket. It can be installed in excavator of 1.2-40 tons. The operator can have flexible choices
2. With all functions of bucket, it can load/unload and delivery shrub, wood, stone, waste, iron tools and pipe
3.The cylinder is equipped with check valve, more safety for grabbing
4.One machine has multiple applications and higher efficiency
5.Big cylinder is used to make sure strong clamping power
|
Item/Model项目/型号 |
Unit |
UT-GB02 |
UT-GB03 |
UT-GB04 |
UT-GB06 |
UT-GB08 |
UT-GB10 |
UT-GB17 |
UT-GB20 |
|
Weight 重量 |
kg |
110 |
260 |
290 |
690 |
1190 |
1780 |
2100 |
2400 |
|
Max jaw opening开口尺寸 |
Mm |
827 |
1300 |
1400 |
1800 |
2300 |
2500 |
2500 |
2700 |
|
Oil Pressure 油压 |
Kg/cm2 |
100-130 |
110-140 |
120-160 |
150-170 |
160-180 |
160-180 |
180-200 |
180-200 |
|
Set up pressure 设定压力 |
Kg/cm2 |
157 |
170 |
180 |
190 |
200 |
210 |
220 |
250 |
|
Operating Flux 工作流量 |
L/Min |
15-40 |
30-55 |
50-100 |
90-110 |
100-140 |
130-170 |
180-250 |
250-320 |
|
Cylinder volume 油缸容量 |
L |
4 |
5.4 |
5.4 |
8.2 |
10 |
12 |
14 |
15 |
|
Suitable Excavator 适配挖机 |
Ton |
2-3 |
4-6 |
7-11 |
12-16 |
17-23 |
24-30 |
31-40 |
41-50 |
The specifications may vary with different excavators and are subject to change without prior notice for products improvement.
