Feature
Features ：
1. Using the new type of steel, high abrasion resistance, light weight, large opening.
2. Stable performance cylinder, provide additional power to ensure normal operation in various environments.
3. The grease can be injected into the sealing parts perfectly through special parts, and the wear of pins and bushes can be reduced.
|
Item/Model 项目/型号 |
Unit |
UTHP15S |
UTHP20S |
UTHP25S |
|
|
Suitable Excavator 适配挖机 |
ton |
15 |
18-24 |
35 |
|
|
Weight 重量 |
kg |
1320 |
1500 |
1750 |
|
|
Opening 开口 |
mm |
620 |
760 |
900 |
|
|
Depth 深度 |
mm |
700 |
830 |
1000 |
|
|
Height 高度 |
mm |
2060 |
2250 |
2620 |
|
|
Width 宽度 |
mm |
|
|
|
|
|
Lenght 长度 |
mm |
1050 |
1340 |
1580 |
|
|
Rated Pressure 额定压力 |
|
|
|
|
|
|
Rated flow 额定流量 |
lpm |
230 |
240 |
260 |
|
|
Crushing force粉碎力 |
Middle中央 |
ton |
40 |
50 |
65 |
|
Tip 尖端 |
ton |
40 |
50 |
65 |
|
|
Cycle time周期 |
Open张开 |
sec |
2.1 |
2.2 |
2.5 |
|
Close 闭合 |
sec |
2.1 |
2.2 |
2.5 |
|
具体数据根据挖掘机型号及索赔设备尺寸有所浮动, 产品不断改进升级中,数据改动不再另行通知。
The specifications may vary with different excavators and are subject to change without prior notice for products improvement.
