Feature
Features:
1. The vibro ripper has changed the principle of using the piston impact type of crushing. Compared with the hydraulic breaker, it effectively avoids the damage of the black oil or metal debris to the excavator's hydraulic system, and effectively avoids through a reasonable mechanical structure. The hammer's own damage to the big and small arms of the excavator through a reasonable mechanical structure.
2. The vibro ripper has many features such as ”high efficiency, energy saving, and environmental protection”
3. If meet the working conditions, the output can reach 3-5 times that of piston breaker installed on same level excavator.
4. Under the same conditions, the overall fuel consumption of the high- frequency breaker is 30% lower than that of the piston breaker, and the construction noise is only 50-75 dB, which fully meets the requirements of urban and even night construction.
5. Underwater construction can be performed under conditions of simple modification
|
Item/Model 项目/型号 |
Unit |
UTVR20 |
UTVR30 |
UTVR40 |
UTVR50 |
UTVR60 |
UTVRE5 |
UTVRE6 |
UTVRD6 |
UTVRD8 |
UTVRD10 |
|
|
Power 功率 |
kw |
60 |
68 |
79 |
95 |
120 |
140-180 |
180-200 |
160-200 |
190-230 |
210-240 |
|
|
Motor model 马大型号 |
cc |
80 |
90 |
108 |
125 |
160 |
90*2 |
108*2 |
90*2 |
108*2 |
130*2 |
|
|
Impact power 冲击力 |
kn |
251 |
286 |
300 |
370 |
430 |
450 |
691 |
468 |
599 |
736 |
|
|
Size |
Length长 |
mm |
2300 |
2700 |
2700 |
2800 |
3100 |
3400 |
3685 |
4500 |
4800 |
4850 |
|
Width宽 |
mm |
950 |
1200 |
1200 |
1250 |
1250 |
1207 |
1246 |
1300 |
1300 |
1400 |
|
|
Height高 |
mm |
1350 |
1500 |
1500 |
1550 |
1650 |
1780 |
1815 |
1650 |
1850 |
1850 |
|
|
Working flow 工作流量 |
L/min |
144-180 |
160-200 |
190-220 |
225-250 |
288-295 |
324-295 |
410-440 |
360-400 |
420-460 |
450-500 |
|
|
Working Pressure 工作压力 |
Mpa |
25 |
25 |
25 |
25 |
25-26 |
25-26 |
25-26 |
25-28 |
25-28 |
25-28 |
|
|
Weight 重量 |
kg |
3000 |
3600 |
3800 |
4300 |
5000 |
5500 |
6200 |
6500 |
7600 |
9200 |
|
|
Suitable excavator 适配挖机 |
ton |
15-20 |
22-26 |
28-30 |
30-33 |
36-45 |
38-45 |
50-65 |
50-65 |
70-90 |
100-190 |
|
The specifications may vary with different excavators and are subject to change without prior notice for products improvement.
